Automating your Backyard Observatory Part 2 | Controlling your Roof in NINA

In this video I go over how to automate/control your roll off roof backyard observatory in NINA. We are joined by Glenn from the Astrobloke channel and show him the software and go over the install. Lastly we test our installation with an advanced sequence in NINA.
Special thanks to Bruce Garner - https://www.youtube.com/user/Br00se
Thanks to Glenn as well for helping me test - https://www.youtube.com/c/Astrobloke

Hardware - These are affiliate links
Arduino Uno - https://amzn.to/2X3otMu
Arduino Relay Shield - https://amzn.to/38O84Of
Arduino Screw Shield - https://amzn.to/3tnZ9wf
Sensors - https://amzn.to/3yMD9fO
You must insure you get sensors that are the normally closed type, normally open will not work correctly. The sensors I bought are no longer available, but I linked some above that should work. Any normally closes sensor should work.

Gate motor I'm using for roof - https://amzn.to/3zWGmdW
18AWG silicone wire - https://amzn.to/38PhxF2

Software Links
Adruino IDE- https://www.arduino.cc/en/software

RRCI Ascom- https://create.arduino.cc/projecthub/cfar/rolling-roof-computer-interface-rrci-fb851f?f=1

SKYROOF- https://interactiveastronomy.com/support.html

Arduino Uno required modified code- https://drive.google.com/file/d/1oEkFpWK0uaBSon9Ecq-tWgPqEEtIpN6L/view?usp=sharing


00:00 Intro
00:24 Overview and sensors
06:12 Hardware
11:50 Software
24:27 Setup and testing
